ETC Installation Guide
Pro One-Cell
Installation Spacing - High Output Luminaires
ArcSystem Pro One-Cell High Output luminaires must be installed with the spacings listed below.
Install with minimum spacings between
a. Center-to-center of adjacent luminaires: 609.6 mm (24 in)
b. Top of luminaire to overhead building member: 76.2 mm (3 in)
c. Luminaire center to side building member: 304.8 mm (12 in)
Supplies
The following supplies are required, but not provided:
½ in flexible conduit and conduit fittings, as needed
•
Romex or nonmetallic screw-clamp style conduit connectors for outputs
•
Phillips screwdriver
•
Four #10 screws and other mounting hardware as needed
•
Note:
conduit hardware, and all cable required for installation.
Electrical and Wiring Specifications
Install the driver on a power distribution system with reliably identified earthed neutral (ground) and
install a maximum 20 A circuit breaker on the line conductor. The D1, D2, and D4 Series drivers
accept 100–277 VAC, 50/60 Hz. ETC recommends installing all wiring in grounded metal conduit.
WARNING:
device cannot be serviced or operated safely.
AVERTISSEMENT :
installés sans qu'un dispositif de déconnexion de l'alimentation ne soit
accessible.
Pro One-Cell
Mounting hardware and installation location must support the weight of the driver,
Circuits that are installed without an accessible power disconnect
Il est imprudent d'utiliser ou de réparer les circuits
