ETC Installation Guide
Pro One-Cell
Power Up and Control
Final Installation
ArcSystem D1, D1 HO, D2, and D4 drivers and ArcSystem multi-cell luminaires are supplied with a
5 dB antenna providing 90 degree omni-directional coverage. Install this antenna to the antenna
receptacle.
Note:
periodically due to built-in protection against overheating. Leave the lamp on for several
hours to check for overheating caused by improper installation. The driver can overheat
even if the lamp is off.
Power Up Procedure
1.
Check that luminaire power switch is on, if applicable.
2.
Check the DMX control source to ensure proper installation and termination per the
manufacturer's instructions.
3.
Apply power at the main circuit breaker.
After the power up procedure, the luminaire will light.
Note:
allows an electrical contractor to check that all products are properly installed and wired.
During system commissioning, the certified ETC technician will remove this setting and
configure DMX addresses for normal use. During normal use after commissioning is
complete, ArcSystem luminaires will light if the DMX Control level is greater than 0.
DMX System Control
ArcSystem with ArcMesh can be installed and controlled over the wireless ArcMesh protocol, hard
wired DMX, or a hybrid of the two, making it a great solution for both new construction and retrofit
situations.
ArcSystem RDM Systems can be controlled over wired DMX from a lighting console or ETC Concert
software. Concert is available for free download at etcconnect.com/Concert.
ArcSystem is compliant with DMX 512-A (ANSI E1.11-2008 (R2013)).
•
DMX loss behavior is hold last look.
•
Each luminaire can be addressed to any one of the 512 DMX addresses up to the maximum device
limit of 32 devices on each DMX line. Wireless DMX control requires a TX1 Transmitter and
luminaires with the wireless ArcMesh transceiver. For wireless DMX installation,there are up to 64
control channels available. See the ArcSystem Installation Manual , available from etcconnect.com.
Channels can be grouped and programmed into presets per the needs of your space. Groups and
presets can be recalled through a lighting console or other devices.
Both wired and wireless products can be used within a single system. The following graphic shows
an example of how a system with wired luminaires, wireless luminaires, and a transmitter may be
installed.
Pro One-Cell
Incorrect installation of recessed luminaires may cause output to turn on and off
All ArcSystem luminaires are factory set to provide 100% output level. This
Page 23 of 29
