ETC Installation Guide
Pro One-Cell
S4
S3
Switch
blocks
S2
S1
Pro One-Cell
A
A
Constant Current with Molex connectors
B
Constant Current with terminal outputs
C
Constant Voltage with terminal outputs
B
D4 Driver
Page 13 of 29
LED4
LED3
Output type
varies by model
LED2
LED1
C
ETC
