XVME-400/40l/490/491 Manual
October, 1989
MANUAL
STRUCTURE
1.2
The chapters in this manual are structured as follows:
Chapter One -
Chanter Two -
Chapter Three -
Appendix A -
Appendix B -
Appendix C -
This manual (XYCOM part # 74400-002) is part of a manual kit
(XYCOM part # 74400-001) that is being shipped with the
XVME-400/401/490/491
Manual' (referenced as XYCOM part # 74400-003).
This manual discusses module base addressing, register access
offsets, interrupt control, handshake control, and operational
mode/programming constraints. To better understand these topics,
is it recommended that you first read the 8530 Manual.
1 Z8030/Z8530 SCC Serial Communications Controller Technical Manual, Zilog, January, 1983.
A general description of the XVME-400/40 l/490/49 1 modules,
including complete functional and environmental specifications,
VMEbus compliance information, and block diagrams.
Module installation information, covering module-specific
system requirements, jumpers, and connector pinouts.
Details covering functional addressing, interrupt enabling, and
programming
considerations
VMEbus connector and pin descriptions.
Quick reference guide with jumper configurations.
Block diagrams, assembly drawings, and schematics.
NOTE
Modules. The kit also contains an 8530
l-2
and
requirements.
