Xycom XVME-400 Manual page 57

XVME-400/40l/490/491 Manual
October, 1989
Jumper
Jl
JAl0-JAI5
JAI-JA3
Jumper
Jl and J2
J3-J6
J7
JAI0-JAI5
JAI-JA3
QUICK REFERENCE GUIDE
Table B-l. XVME-400 and XVME-490 Jumper List
Determines whether the module will respond to supervisory or
supervisory and non-privileged short I/O VMEbus cycles (refer to
Section 2.4.2 of this manual).
Select module base address on any one of the 64 1K boundaries
within the short I/O address space (refer to Section 2.4.1 of this
manual).
Select the VMEbus interrupt level for the module (refer to Section
2.4.3 of this manual).
Table B-2. XVME-401 and XVME-491 Jumper List
Bring the +5V supply to front-edge connectors JKl and JK2,
respectively (XVME-401 only; refer to Section 2.4.4).
Allows tri-stating of any of the channels (refer to Section 2.4.5).
Determines whether the module will respond to supervisory or
supervisory and non-privileged short I/O VMEbus cycles (refer to
Section 2.4.2).
Select module base address on any one of the 64 IK boundaries
within the short I/O address space (refer to Section 2.4.1).
Select the VMEbus interrupt level for the module (refer to Section
2.4.3).
Appendix B
Use
Use
B-l
