XVME-400/401/490/491 Manual
October, 1989

1.4 MODULE SPECIFICATIONS

The following is a list of the operational and environmental specifications for the
XVME-400/40l/490/491 Modules.
Table l- 1. XVME-400/40l/490/491 Module Specifications
Characteristic
Number of Channels
Serial Device
Level
Compatibility:
XVME-400/490
XVME-401/491
Maximum Baud Rate:
Internal, async
Internal,
External, async
External,
Modem Control Signals Available
XVME-400/40 l/490
XVME-49 1
Power
Requirements
XVME-400/490
XVME-40 l/49 1
Temperature
Operating
Non-operating
Humidity
Altitude
Operating
Non-operating
sync
sync
Specification
4
Zilog 28530
RS-232C
RS-485/422A
57.6 Kbytes
500 Kbytes
57.6 Kbytes
500 Kbytes
RTS, CTS, DCD, DTR
RTS, CTS, DCD
+5V @ 1.1 A typ., 1.3 A max.
+12V @ 100 mA typ., 110 mA max.
+5V @ 1.4 A typ., 1.6 A max.
0 to 65'C (32 to 149'F)
-40 to 85'C (-40 to 158'F)
5 to 95% RH non-condensing
(Extremely low humidity may require
protection against static discharge.)
Sea level to 10,000 ft. (3048 m)
Sea level to 50,000 ft. (15240 m)
1-5
