2.5.1.1 JKl and JK2 Connector Pinouts on the XVME-400 (RS-232C)
Table 2-8 shows the XVME-400 pinout connectors JKl and JK2. These signals meet the
RS-232C specifications.
Table 2-8. XVME-400 Front Edge Connector Pin Definitions
Pin
Number
3
5
7
8
9
13
14
1 5
22
28
30
32
3 3
34
3 8
39
40
47
All XVME-400 signal names are in the form XXXN where "N" is the
serial channel number and '(XXX" is the name of the signal.
All JKl and JK2 pin numbers not referenced are not connected.
The pinouts of JKl and JK2 allow a 50-conductor flat cable to be connected, split into
two 25-conductor sections, and have 25-pin D-type connectors installed on the two
25-conductor sections. The position of the signals relevant to the 25-pin D-type connectors
will be in accordance with the RS-232C definition (no line transitions are required):
TXD
RXD
RTS
C T S
GND
JKl JK2
Signal Signal
TXDO TXDl
RXDl
RXDO
RTSO RTSl
RXCO Ch. 0 RXCl Ch. 1
CTSl
CTSO
GND GND
DRTO DTRl
DCDO DCDl
TXCO TXCI
TXD2 TXD3
RXD2 RXD3
RTS2 RTS3
RXC2 Ch. 2
RXC3 Ch. 3
CTS3
CTS2
GND GND
DTR2 DTR3
DCD2
DCD3
TXC2 TXC3
Pi n 2
Pi n 3
Pi n 4
Pi n 5
Pin 7
N O T E
DCD Pin 8
RX C Pi n 1 7
DT R Pi n 20
TXC Pi n 24
2-12
Signal
Transmit Data
Receive Data
Request To Send
Receiving Clock
Clear To Send
Ground
Data Terminal Ready
Data Carrier Detected IN
Transmitting Clock
Transmit Data
Receive Data
Request To Send
Receiving Clock
Clear To Send
Ground
Data Terminal Ready
Data Carrier Detected IN
Transmitting Clock
Direction
OUT
I N
O U T
I N
I N
OUT
OUT
OUT
I N
O U T
I N
I N
OUT
OUT
