Sources of JKl /JK2. or P2 Connector
TXD/SD SCC output pin TXD drives a line driver. Driver output is sent to this pin.
RTS/RS SCC output pin RTS* drives a line driver. Driver output is sent to this pin.
TXC/TT SCC output pin TRXC drives a line driver. Driver output is sent to this pin.
DTR/TR SCC output pin DTR* drives a line driver. Driver output is sent to this pin.
Destinations of JK 1 /JK2. or P2 Connector
RXD/RD This input pin is buffered by a line receiver and is driven to the SCC input pin
RXD.
CTS/CS This input pin is buffered by a line receiver and is driven to the SCC input pin
CTS*.
RXC/RT This input pin is buffered by a line receiver and is driven to the SCC input pin
RTXC.
DCD/RR This input pin is buffered by a line receiver and is driven to the SCC input pin
DCD*.
Output
Signals
Input
Signals (one set for each serial channel)
