XVME-400/40l/490/491 Manual
October, 1989
Table l- 1. XVME-400/40 l/490/49 1 Module Specifications (cont.)
Characteristic
Vibration
Operating
Non-operating
Shock
Operating
Non-operating
VMEbus Compliance
VMEbus Timing:
DSO Asserted to DTACK Asserted (Read)
DSO Asserted to DTACK Asserted (Write)
IACKIN Asserted to
DSO Negated to DTACK Negated (All)
IACKIN Asserted to IACKOUT Asserted
Specification
5 to 2000 Hz
0.0 15" peak-to-peak displacement
2.5 g peak acceleration
5 to 2000 Hz
0.030" peak-to-peak displacement
5.0 g peak acceleration
30 g peak acceleration,
11 msec duration
50 g peak acceleration,
11 msec duration
- Complies with VMEbus Specification,
- A16:D8(0) DTB Slave
-
-
- XVME-400/401: Single form factor
Asserted (IACK) - 1100 1200
DTACK
1-6
Interrupt vector D08(0)DYN
I(1) to I(7) interrupter (STAT), ROAK
XVME-490/491: Double form factor
Typ(ns)
650 - 800
650 - 800
60
-
300
IEEE 1014
Max(ns)
100
400
