XVME-400/40l/490/491 Manual
October, 1989
Jumper
Jl (XVME-400/490) , or
J7 (XVME-401/491)
In
o u t
JA3
In
In
In
In
out
out
out
out
Jumper
Jl
J2
Table B-3. Addressing Options
Address Modifier to which the
XVME-400/40l/490/491 Module will respond
(2DH) Supervisory only
(2DH) Supervisory or (29H) Non-privileged
Table B-4. Interrupt Level Jumper Positions
JA2 JAI
In In
In out
In
o u t
out
out
In In
In out
In
out
out out
Table B-5. +5V Jumpers (XVME-401 only)
If J1 is installed, +5V will be connected to JKl (pin 47).
If Jl is removed, JKl-47 will float.
If J2 is installed, +5V will be connected to JK2 (pin 47).
If J2 is removed, JK2-47
Interrupt Level Selected
None, VMEbus Interrupter disabled
Level 1
Level 2
Level 3
Level 4
Level 5
Level 6
Level 7
Use
will float.
B-2
