XVME-400/40l/490/491 Manual
October, 1989
Table 2-10. XVME-490 Rear Edge P2 Connector Pin Definitions (Cont'd)
Pin #
1 7
1 8
1 9
20
2 1
22
23
24
25
26
27
28
29
30
3 1
32
All P2 signal names are of the form "XXXN" where "N" is the serial
channel number and "XXX' is the name of the signal. Signals with
the same "XXX" function identically with respect to the particular
channel.
Row A Signal
TXD2
RXD2
RTS2
RXC2 Ch. 2
C T S 2
DTR2
DCD2
TXC2
TXD3
RXD3
RTS3
RXC3 Ch. 3
CTS3
DTR3
DCD3
TXC3
NOTE
2-15
Row B Signal
N C
N C
N C
N C
N C
GND
N C
N C
N C
N C
N C
N C
N C
N C
GND
v c c
Row C Signal
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
