Action
Ensure:
•
•
Before power up
•
•
•
Ensure:
Power up the
drive
•
Enter minimum Enter:
and maximum •
speeds
•
Enter
Enter:
acceleration and
•
deceleration
•
rates
Enter:
•
Enter motor •
nameplate
•
details •
•
Ready to autotune
Enable and run Close:
the drive
•
The VFD67 will carry out a non-rotating autotune on the
motor.
The motor must be stationary to carry out an autotune
Autotune correctly.
The drive will carry out a non-rotating autotune every time it
is first started after each power-up. If this will cause a
problem for the application, set Pr 41 to the required value.
When the autotune has been completed, the display will show:
Autotune
complete
Ready to run
Run The drive is now ready to run the motor.
Increasing and Turning the speed potentiometer will increase and decrease
decreasing speed the speed of the motor.
To stop the motor under ramp control, open either the run
forward or run reverse terminal.
Stopping
If the enable terminal is opened while the motor is running,
the motor will coast to a stop.
VFD67 Size A to D Getting Started Guide
Issue Number: 1
The drive enable signal is not given, terminal B4 is open
The run signal is not given, terminal B5/B6 is open
The motor is connected to the drive
The motor connection is correct for the drive Δ or Y
The correct supply voltage is connected to the drive
The drive displays:
Minimum speed Pr 01 (Hz)
Maximum speed Pr 02 (Hz)
Acceleration rate Pr 03 (s/100Hz)
Deceleration rate Pr 04 (s/100Hz)
Motor rated current in Pr 06 (A)
Motor rated speed in Pr 07 (rpm)
Motor rated voltage in Pr 08 (V)
Motor rated power factor in Pr 09
If the motor is not a standard 50/60Hz motor, set Pr 39
accordingly
The Enable and Run Forward or Run Reverse signals
www.johnsoncontrols.com
Detail
Pr 02
Pr 01
t
100Hz
t
Pr 03 Pr 04
Mot X XXXXXXXXX
No XXXXXXXXXX kg
°
IP55 I.cl F C 40 s S1
V Hz min -1 kW cosφ A
230 50 1445 2.20 0.80 8.50
400 4.90
CN = 14.5Nm
240 50 1445 2.20 0.76 8.50
415 4.90
CN = 14.4Nm
CTP- VEN 1PHASE 1=0,46A P=110W R.F 32MN
∅
cos
R
S
σL
S
