B1 Analog voltage output - Motor speed
Voltage output
Scaling
Maximum output current
Resolution
B2
+24V output
Maximum output current
B3
Digital output - User selectable Pr 35
Voltage range
Maximum output current
The total available current from the digital output plus the +24V output is 100mA.
NOTE
B4
Digital Input - User selectable
B5 Digital Input - User selectable
B6
Digital Input - User selectable
B7
Digital Input - User selectable
Logic
Voltage range
Nominal threshold voltage
If the enable terminal is opened, the drive's output is disabled and the motor will coast to
a stop. The drive will not re-enable for 1.0s after the enable terminal is closed again.
Following a drive trip, opening and closing the enable terminal will reset the drive. If the
run forward or run reverse terminal is closed, the drive will run straight away.
Following a drive trip and a reset via the stop/reset key, the enable, run forward or run
reverse terminals will need to be opened and closed to allow the drive to run. This
ensures that the drive does not run when the stop/reset key is pressed.
The enable, run forward and run reverse terminals are level triggered apart from after a
trip where they become edge triggered.
If the enable and run forward or enable and run reverse terminals are closed when the
drive is powered up, the drive will run straight away up to a set speed.
If both the run forward and run reverse terminals are closed, the drive will stop under the
control of the ramp and stopping modes set in Pr 30 and Pr 31.
18
0 to +10V
0V represents 0Hz/rpm output
+10V represents the value in Pr 02 Maximum set speed
5mA
0.1%
100mA
0 to +24V
50mA at +24V (current source)
Positive logic only
0 to +24V
+10V
