On the VFD67 size D, the internal EMC filter is connected to the -DC Bus.
NOTE
The braking terminals are not available on the size A 110V drive.
NOTE
Fuses/MCB
The AC supply to the drive must be installed with suitable protection against overload
and short circuits. Failure to observe this requirement will cause risk of fire.
WARNING
The drive must be grounded by a conductor sufficient to carry the prospective fault
current in the event of a fault. See also the warning in section 4.2 Ground leakage
relating to ground leakage current.
WARNING
To avoid a fire hazard and maintain validity of the UL listing, adhere to the specified
tightening torques for the power and ground terminals. Refer to the table below.
WARNING
Frame size
A
B, C and D
Braking resistor: High temperatures and overload protection
Braking resistors can reach high temperatures. Locate braking resistors so that damage
cannot result. Use cable having insulation capable of withstanding the high temperatures.
WARNING
It is essential that the braking resistor be protected against overload caused by a failure
of the brake control. Unless the resistor has in-built protection, a circuit like those shown
in Figure 4-1 and Figure 4-2 should be used, where the thermal protection device
disconnects the AC supply to the drive. Do not use AC relay contacts directly in series
with the braking resistor circuit, because it carries DC.
When connecting single phase to a dual rated 200V unit, use terminals L1 and L3.
NOTE
For control terminal connections, see Pr 05 on page 24.
NOTE
For information on the internal EMC filter, see section 4.3.1 Internal EMC filter .
NOTE
4.2

Ground leakage

The ground leakage current depends upon the internal EMC filter being installed. The
drive is supplied with the filter installed. Instructions for removal of the internal EMC filter
are given in section 4.3.2 Removing the internal EMC filter .
With internal EMC filter installed
30μA DC (10MΩ internal bleed resistor, relevant where DC leakage current is being measured)
Size A
1 phase 110V drives
4mA AC at 110V, 50Hz (proportional to supply voltage and frequency)
1 phase 200V drives
10mA AC at 230V, 50Hz (proportional to supply voltage and frequency)
Size B
1 phase 110V drives
10mA AC at 110V, 50Hz (proportional to supply voltage and frequency)
Size B and C
1 phase 200V drives
20mA AC at 230V, 50Hz (proportional to supply voltage and frequency)
14
Maximum power terminal screw torque
0.5 N m / 4.4 lb in
1.4 N m / 12.1 lb in
