4P: Set for a 4 pole motor
6P: Set for a 6 pole motor
8P: Set for an 8 pole motor
No Function
41 Voltage mode select
Ur S: Stator resistance is measured each time the drive is enabled and run
Ur: No measurement is taken
Fd: Fixed boost
Ur A: Stator resistance is measured the first time the drive is enabled and run
Ur I: Stator resistance measured at each power-up when the drive is enabled and run
SrE: Square law characteristic
In all Ur modes, the drive operates in open loop vector mode.
No Function
42 Low frequency voltage boost
Determines the boost level when Pr 41 is set to Fd or SrE.
No Function
43 Serial communications baud rate
2.4: 2400 baud
4.8: 4800 baud
9.6: 9600 baud
19.2: 19200 baud
38.4: 38400 baud
No Function
44 Serial comms address
Defines the unique address for the drive for the serial interface.
No Function
45 Software version
Indicates the version of software installed in the drive.
Pr 46 to Pr 51 appear when Pr 12 is set to control a motor brake.
No Function
46 Brake release current threshold
47 Brake apply current threshold
Defines the brake release and brake apply current thresholds as a % of motor current.
If the frequency is >Pr 48 and the current is >Pr 46, the brake release sequence is started.
If the current is <Pr 47, the brake is applied immediately.
36
Range
Ur S, Ur, Fd, Ur A, Ur l, SrE
Range
0.0 to 50.0 %
Range
2.4, 4.8, 9.6, 19.2, 38.4
Range
0 to 247
Range
1.00 to 99.99
Range
0 to 200 %
VFD67 Size A to D Getting Started Guide
www.johnsoncontrols.com
Defaults Type
Fd RW
Defaults Type
1.0 RW
Defaults Type
19.2 RW
Defaults Type
1 RW
Defaults Type
RO
Defaults Type
50
RW
10
