Table 2-4 VFD67, 3 phase, 380 to 480VAC ±10%, 48 to 62Hz units
Nominal
Model
motor power
Number
kW
VFD67CBB 0.37
VFD67CCB 0.55 0.75
VFD67CDB 0.75
VFD67CEB 1.1
VFD67CFB 1.5
VFD67CGC 2.2
VFD67CHC 3.0
VFD67CJC 4.0
VFD67CKD 5.5
VFD67CMD 7.5 10.0
Output frequency
0 to 1500Hz
Output voltage
110V drives:
3 phase, 0 to 240Vac (240 Vac maximum set by Pr 08).
110V drives contain a voltage doubler circuit on the AC input.
NOTE
200V and 400V drives:
3 phase, 0 to drive rating (240 or 480Vac maximum set by Pr 08).
The output voltage can be increased by 20% during deceleration. See Pr 30 on page 33
NOTE
The maximum continuous current inputs are used to calculate input cable and fuse
NOTE
sizing. Where no maximum continuous input currents are indicated, use the typical full
load input current values.
10
Input Typical full
fuse load input
rating current
hp A A
0.5 6 1.7
6 2.5
1.0 6 3.1
1.5 6 4.0
2.0 10 5.2
3.0 16 7.3
4.0 16 9.5
5.0 16 11.9
7.5 16 12.4
20 15.6
www.johnsoncontrols.com
100% RMS
Maximum
output
continuous
current
input current
A
A Heavy Duty
2.5 1.3
3.1 1.7
3.75 2.1
4.6 2.8
5.9 3.8
9.6 5.1
11.2 7.2
13.4 9.0
14.3 13.0
16.9 16.5
VFD67 Size A to D Getting Started Guide
150% overload
Minimum
current for 60s
braking
resistor value
A
Ω
1.95 100
2.55 100
3.15 100
4.2 100
5.7 100
7.65 100
10.8 55
13.5 55
19.5 53
24.75 53
