Figure 6-2 Pr 05 = AV.Pr (voltage input and 3 presets)
T4
B7
0
0
0
1
1
0
1
1
Figure 6-3 Pr 05 = AI.Pr (current input and 3 presets)
T4
B7
0
0
0
1
1
0
1
1
VFD67 Size A to D Getting Started Guide
Issue Number: 1
10k
(2kmin)
_
+
V
Reference selected
A1
Preset 2
Preset 3
Preset 4
Remote speed
reference input
_
V
Reference selected
A1
Preset 2
Preset 3
Preset 4
www.johnsoncontrols.com
T1
0V
Local voltage speed
T2
reference input (A1)
T3
+10V reference output
T4
Reference select
Analog output
B1
(motor speed)
B2
+24V output
Digital output
B3
(zero speed)
B4
/Stop
B5
Run
B6
Jog
B7
Reference select
T1
0V
Remote current speed
T2
reference input (A1)
T3
+10V reference output
T4
Reference select
+
Analog output
B1
(motor speed)
B2
+24V output
Digital output
B3
(zero speed)
B4
/Stop
B5
Run
B6
Jog
B7
Reference select
25
