1. INTRODUCTION

This 4 by 2 HDMI Matrix with PiP is a high performance HDMI switch with
integrated scaling and multi-windowing technology which can connect up
+
to four 4K UHD HDMI sources to up to two 4K UHD
freely switch between them. It is an ideal solution for monitoring or displaying
multiple sources simultaneously for use in control rooms, conference rooms
or classrooms. Video resolutions up to 4K@60Hz and LPCM audio up to 7.1
channels at 192kHz are supported and this unit is fully compatible with the
HDCP 1.x and 2.2 standards.
Any of 4 different HDMI sources may be displayed individually, full screen,
with seamless switching in Matrix mode, or they can be displayed using a
variety of multi-window modes including standard views like PiP (Picture in
Picture) and PoP (Picture outside of Picture) as well as fully customizable
quad-window modes. Control of input/window routing, position and sizing is
easy using the front panel controls with OSD menu as well as by WebGUI,
RS-232, and Telnet.

2. APPLICATIONS

• Entertainment Room & Home Theater
• Show Room & Demo Room
• Lecture Room & Hall Presentation
• Public Commercial Display

3. PACKAGE CONTENTS

+
• 1× UHD 4×2 HDMI Matrix with PiP
• 1× 24V/2.7A DC Power Adapter
• 1× Rackmount Ears (Set of 2)
• 1× Shockproof Feet (Set of 4)
• 1× Operation Manual
1
+
HDMI displays and
