1. INTRODUCTION

The PU-8H8HBTL is an 8x8 HDMI HDBaseT™ Lite Matrix. Installers can
switch and distribute up to 8 HDMI sources, and 2-Way IR to lengths of up
to 60m using CAT5e/6/7 cable infrastructure. Control of the matrix is via
IP, RS-232, IR remote, or manual selection buttons. This single box solution
will enable an installer to confidently integrate an eight zone multi-room
AV system. The PU-8H8HBTL is designed to be used with the PU-514L-RX
Receiver which enables the use of 2-Way IR control feature.

2. APPLICATIONS

HDMI Matrix System
Video/TV wall display and control
Security surveillance and control
Commercial advertising, display and control
University lecture hall, display and control
Retail sales and demonstration

3. PACKAGE CONTENTS

HDBaseT™ Lite 8×8 HDMI Matrix
9×IR Receiver
9×IR Emitter
1×24 V/6.25 A DC Power Adaptor
1×IR Remote Control
Operation Manual
