3) In 1~4 EDID: Select the EDID to assign to the specified input.
Note: Only available in the "Independent" EDID Mode.
4) User 1~4 EDID: To update any of the unit's 4 User EDIDs via USB,
select "Yes" next to the appropriate User EDID and then insert a USB
stick containing the new EDID into the Service port. The upload will occur
immediately.
Note: The USB stick must contain, in the root directory, a compatible and
properly named (EDID_User_*.BIN) EDID file.
HDCP Mode
2ND LEVEL
In 1~4
OUT A
OUT B
Win 1
Win 2
Win 3
Win 4
1) In 1~4: Select the HDCP behavior for each input.
„ HDCP Support Off: Completely disables support for HDCP on
that input.
„ Refer to Source: Makes the input port support the same HDCP
version as required by the connected source.
„ Refer to Display: Makes the input support the HDCP version of
the currently connected displays.
2) HDCP Status: Displays the current HDCP status of all sources and
outputs.
3RD LEVEL
HDCP Support Off
Refer to Source
REFER TO DISPLAY
[Current HDCP
status display]
16
