6-roller 70 mm mover

11.4

12-roller 50 mm mover

11.5
Version: 2.2
11.4
The roller set is available to replace worn or damaged guide rollers
in the 70 mm long movers with 6 guide rollers:
• AT9011-0070-0550
• AT9011-0070-1550
Scope
• 4 x cylindrical guide rollers with short shoulder bolts
• 2 x wide cylindrical guide rollers with long shoulder bolts
11.5
The roller set is available to replace worn or damaged guide rollers
in the 50 mm long movers with 12 guide rollers :
• AT9012-0050-0550
• AT9012-0050-1550
Scope
• Packaging with foam insert for the guide rollers
• Installation instructions on the label on the inside of the lid
• 4 cylindrical guide rollers
• 4 conical guide rollers
• 2 cylindrical guide rollers, lower
• 2 conical guide rollers, lower
With the label on the inside of the packaging lid you have
the option to read out the QR code and to watch an anima-
tion about the steps of the installation instructions.
