Mechanical installation
68
───
► Connect further modules in line and fix them hand tight in the
center to the machine bed with screws and washers 1 and 2
► Maintain distance 3 by using the alignment gauge [+] or a vernier
caliper during the installation
► Make sure that the modules are slightly movable in the slots
XTS
Version: 2.2
