A complete XTS system consists of:
• Motor modules
• Guide rails
• Movers
The individual components are defined via the type key and can be
ordered separately or preconfigured as a complete system.
A system consists of individual motor modules that can be combined
to form a complete drivetrain. The straight and curved modules are
each available in different versions:
3.4.1.1
Length [mm]
250
249
233
3.4.1.2
22.5° motor module
This module is available with a +22.5° or a -22.5° curve, with or
without supply.
XTS
Supply
• without supply
• with supply
• with supply and UL
• with plug
• with plug
• without supply
Version: 2.2
