Knowing What is Happening on the
Line (Graphic Meters)
There are two indicators which appear on the display during calls to help
you monitor sounds on the line. These meters do not appear during non-
captioned calls.
The Signal Meter
The Signal Meter lights up to indicate sounds on the handset, such as the
caller's voice or a busy signal. It indicates that a sound is coming through
the handset even if the sound is not loud enough for you to hear. The size
of this meter expands and contracts with the volume of the sound. Very
loud sounds cause the meter to completely light up the whole box. Quiet
sounds may cause just a single dot on the
display to light up. This meter can help you
gauge when a person is finished speaking.
The Outgoing Volume Meter
The Outgoing Volume Meter lights up when
you speak. This can help you see how loudly
you are speaking. More of the bar lights up if
you speak loudly and less lights up if you speak quietly.
ADJUSTING THE SOUND 13
■
