Infinea X User Manual
Infinea X Layout
SKUs: IX-Z2DBTR-PH7-BK and IX-Z2DBTR-PH7-MG
iPhone receiver port
T6 screw
Volume
Buttons
T6 Screw
Status LED
T6 Screw
iOS Home Button
iOS On/Off
Button
Programmable
Button
T6 Screw
iOS On/Off
Button
Scan Button
T6 Screw
Status LED
Programmable
Button
T6 Screw
Scan Button
iOS Camera opening
Barcode Scanner
Battery latch
Volume Buttons
Battery Status
Button
RFID/HID
antenna
Battery pack
7
