Infinite Peripherals INFINEA X Quick Start Manual

INFINEA® X
Charging Station
(1-Unit)
iPod 6, iPhone SE &
iPhone 7
QUICK START GUIDE

GETTING STARTED

1. Place the charging station on a sturdy, clean and
dry surface in an open, well-ventilated area away
from direct sunlight.
2. Gently insert the bottom of the device into the
charging cup, ensuring the unit is seated upright so
that proper contact is made with the charging pins
(Fig. 1).
3. Plug USB (Fig. 2) connector end of Infinea X
Charging Station into an appropriate power supply
(5.2V 2.4A, not included).
4. Confirm the Infinea X LED indicator turns green to
indicate charging is active.
5. On the charging station, pull the device straight up
and out of the charging bay.
ABOUT YOUR INFINEA® X

PRODUCT SPECIFICATIONS

Compatibility
Infinea X with iPod 6, iPhone SE, or
iPhone 7
Weight
450g (15.9 oz.)
Dimensions
121 mm x 106.3 mm x 54.5 mm
(4.8" x 4.2" x 2.15")
Cable Length 3' (914.4 mm)
Connector USB A
Input 5V 2.1A DC (Minimum)
Operating 0°F to 35°F (32°C to 95°C)
Temperature
Storage Temperature -20°F to 45°F (-4°C to 113°C)
Relative Humidity 5% to 95% Non-Condensing
CHARGING STATION (1-UNIT)
1
Mechanical
Infinea X with iPhone 7
460g (16.2 oz.)
121 mm x 106.3 mm x 61.4 mm
(4.8" x 4.2" x 2.4")
Electrical
Environmental
2
