Overview

The Infinea X for iPhone allows you to scan barcodes and read RFID
tags or cards.

Infinea X Features

Before using the Infinea X, the battery should be fully charged. These
are the key features of the Infinea X.
Note
Use of the barcode scanner or contactless card reader requires the
installation of special software. Contact your Infinite Peripherals
account executive for compatible third-party software solutions.
Feature Description
Barcode Supports one-dimensional (1D) and two dimensional (2D)
Scanner barcode symbols, which can be read in any direction (omni-
directional). The effective reading distance of the barcode
reader varies depending on the barcode size. The barcode
scanner is capable of reading barcodes on a LCD screen.
RFID Radio Frequency Identification (RFID) tag/card reader with
read and write capability at 13.56 MHz.
Audio Built-in, front and rear amplified speakers, which are
programmable through the Universal SDK.
Battery User-replaceable, Li-ion battery.
Indicators Three programmable indication features: audible, visual and
haptic. An Internal electro-magnetic buzzer provides the
audible indicator. For visual indications, there are 4 multi-color
SDK programmable LEDs (blue, green, red and orange). These
LEDs also provide battery status. The haptic indicator is a
programmable vibration motor.
Power Onboard fuel gauge facilitating accurate monitoring of
Monitoring significant battery attributes using the SDK.
Bluetooth Available Bluetooth 2.0 SPP compatibility, which allows
connection to a Bluetooth peripheral such as a printer.
Case The case is IP54 rated for protection against dust and fluid
ingress. The case material is antimicrobial, which inhibits
growth of bacteria on the product.

Getting Started

Infinea X scans barcodes and passes that data into compatible iOS
applications. To get you up and running with your new Infinea X,
review these sections.
Note
Observe any notes, cautions, or warnings throughout this guide for
additional information, special care required, or important points to
prevent injury or adverse affects.
What Why
Install the The Infinea X battery
battery is shipped with
approximately 30%
of the full charge
capacity.
Ensure the battery is
Charge the
fully charged before
Infinea X
first use.
Install Software To use the barcode scanner,
RFID reader, and LED
status indicators require
the installation of software
on your iOS device.
Turn on the Initialize the scanner and
Infinea X reader functionality for use.
Where
Installing the
Infinea X Battery
Pack
Charging Your Infinea X
Developing Applications
Powering On Your
Infinea X
