Infinite Peripherals INFINEA X Quick Start Manual

INFINEA X
®

Battery Charger

(10-Unit)
QUICK START GUIDE
ASSEMBLY
1. Place the Infinea X Battery Charger on a
sturdy, clean and dry surface in an open,
well-ventilated area away from direct
sunlight.
2. Insert the included AC adapter plug into
the DC Jack Port on the charger. Then
connect the AC power adapter to a
power outlet.
3. Insert the battery into a bay, ensuring
that the battery contacts are aligned
with the bay's contacts. The LED will
light up to provide a battery status.
Note: The charger is shipped with the battery
shims already inserted. Simply remove the
shim anywhere an extended battery is to be
inserted.
ABOUT YOUR INFINEA
CHARGE STATUS
The Infinea X Battery Charger uses a tri-color
LED to indicate the charge status.
Check the status LED on each slot to verify
normal charging status. When
the battery is fully charged, the LED indicator
will be green.
Status Indicator LEDS
Not Lit: No battery in battery bay
Red: Charge in progress
Green: Battery is fully charged
®
X BATTERY CHARGER (10 Unit)
STANDARD BATTERY
BATTERY SHIM
BATTERY BAY

TROUBLESHOOTING

The LED does not come on when a battery
is inserted.
• Ensure that the power supply is fully
plugged into the outlet and plugged
into the DC port.
• Insert a new battery.
It takes an excessive amount of time to fully
charge the battery.
• Verify ambient temperature meets the
operating temperature requirements.
Operating: 10° – 35°C (50° – 95°F)
Storage:
DC JACK PORT
CHARGE STATUS
INDICATOR LEDs
0° – 45°C (32° - 113°F)
