Appendix
Setting instructions

11.1.6 Continuous TIG hot wire welding

t [mm] Is [A]
1.5 90
2 135
4 180
6 220
8 260
10 280
t [mm] Is [A]
1.5 90
2 135
4 180
6 220
8 260
10 280
70
Fillet weld PB position
Parent metal: High-alloy
Welding consumable: High-alloy. Ø 1.0 mm
WF Hz [1/s]
(m/min)
0.9
1.2
2.0
2.7
4.0
5.0
Fillet weld PF position
Parent metal: High-alloy
Welding consumable: High-alloy. Ø 1.0 mm
WF Hz [1/s]
(m/min)
0.9
1.2
2.0
2.7
4.0
5.0
IH [A] Vs [cm/min] Welding torch
80
80
80
80
80
80
IH [A] Vs [cm/min]
80
80
80
80
80
80
Wire angle [°]
[°]
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Welding torch Wire angle [°]
[°]
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
099-000236-EW501
25.04.2019
