5.1.10 Connection for workpiece lead
The item described in the following is part of the machine´s scope of delivery.
Item Symbol
1
2
•
Push the cable plug for the hot wire current onto the connection socket (TIG hot wire) and lock by
turning to the right.
099-000236-EW501
25.04.2019
Description
0
Workpiece
Connection socket (TIG hot wire)
Hot wire power, plus potential, workpiece connection
Design and function
Figure 5-11
Transport and installation
35
