11.1.5 Continuous TIG cold wire welding

t [mm] Is [A]
1.5 90
2 135
4 180
6 220
8 260
10 280
t [mm] Is [A]
1.5 90
2 135
4 180
6 220
8 260
10 280
099-000236-EW501
25.04.2019
Fillet weld PB position
Parent metal: High-alloy
Welding consumable: High-alloy. Ø 1.0 mm
WF Hz [1/s]
(m/min)
0.8
1.0
1.8
2.5
3.5
4.5
Fillet weld PF position
Parent metal: High-alloy
Welding consumable: High-alloy. Ø 1.0 mm
WF Hz [1/s]
(m/min)
0.8
1.0
1.8
2.5
3.5
4.5
IH [A] Vs [cm/min] Welding torch
IH [A] Vs [cm/min]
Appendix
Setting instructions
Wire angle [°]
[°]
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Welding torch Wire angle [°]
[°]
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
Forehand 10– 41-42
20
69
