Getting started
Table 4.
1.4.2
Software configuration
●
Install the GUI provided with the package
●
Open the GUI (by clicking on Start -> Programs -> STMicroelectronics -> Advanced
PMBus -> Advanced PMBus Software Application) or simply click on the shortcut of
Advanced PMBus Software Application available on the desktop
●
Click on File -> Connect option or on Connect icon
●
Press the polling button to identify the connected slaves
●
The user can now control/monitor the desired slave by clicking on the slave address.
12/31
www.BDTIC.com/ST
PMBus connector
Pin
1
2
3
4
5
6
7
8
9
10
Doc ID 15846 Rev 1
Description
Control 5
Control 4
Control 3
Control 2
VDD_OUT
GND
Control 1
PMBus Alert
PMBus Clock
PMBus Data
