UNIVERSAL PLATFORM (STRAIGHT CONFIGURATION)
UNIVERSAL PLATFORM (TURN CONFIGURATION)
MPPC – CONNECTOR – PLATFORM TO PLATFORM
MHRRRC – CONNECTOR – RAMP HR TO RAMP HR
MHRPRC – CONNECTOR – PLATFORM HR TO RAMP HR
MBP36, MBP48, MBP60 - BRIDGE PLATE
MSTSXXPR - FEET & SUPPORT TUBE PAIRS
MHREC - HANDRAIL END CAP
XX DENOTES USABLE LENGTH (LENGTHS
AVAILABLE 10" THROUGH 100")
ITEMS NOT SHOWN ACTUAL SIZE
