Section 1: Basic System Components; Identifying Components - EZ-ACCESS Modular Ramp Assembly Manual

1. BASIC SYSTEM COMPONENTS
1.1. Because each ramp configuration will differ from one another, your system may or may not
contain all these basic system components.
MODULAR RAMP WITH HANDRAIL MODULAR RAMP WITHOUT HANDRAILS
MRLT – RAMP LOWER TRANSITION MRRC – CONNECTOR – RAMP TO RAMP
NOTE: INCLUDES
COMPONENTS TO
CONNECT RAMPS
AND RAMP
HANDRAILS.
MRUT – RAMP UPPER TRANSITION MRST - RAMP SUPPORT TOP
MRHBPR - RAMP HANDRAIL END BRACKET (PAIR) MRHRL - HANDRAIL END LOOP
ITEMS NOT SHOWN ACTUAL SIZE
