System Monitoring

Monitoring overview

The Brocade DCX 8510-4 is engineered for reliability and requires no routine operational steps or maintenance. This
chapter provides information about determining the status of each component using LEDs and CLI commands. Refer to
the Brocade Web Tools Administration Guide and the Brocade Fabric OS Administration Guide for additional information.
There are two commands that can be especially helpful in monitoring the health of the Brocade DCX 8510-4. These
commands are
switchShow
Note in the
switchShow
identification for capable ports. The output has been truncated to reduce information duplication.
DCX-4_130:admin> switchshow
switchName: DCX-4_130
switchType: 121.3
switchState: Online
switchMode: Native
switchRole: Principal
switchDomain: 130
switchId: fffc82
switchWwn: 10:00:00:05:33:03:2c:00
zoning: ON (BB)
switchBeacon: OFF
FC Router: ON
FC Router BB Fabric ID: 10
Address Mode: 0
Index Slot Port Address Media
=======================================================
0 1 0 820000
1 1 1 820100
2 1 2 820200
3 1 3 820300
4 1 4 820400
5 1 5 820500
6 1 6 820600
7 1 7 820700
8 1 8 820800
9 1 9 820900
10 1 10 820a00
11 1 11 820b00
12 1 12 820c00
13 1 13 820d00
14 1 14 820e00
15 1 15 820f00
16 1 16 821000
17 1 17 821100
18 1 18 821200
19 1 19 821300
20 1 20 821400
Broadcom
and .
chassisShow
command the new switchType for the Brocade DCX 8510-4 as well as the 16-Gbps speed
Speed State
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
id N8 Online
Proto
FC F-Port 10:00:00:05:1e:f8:a0:b4
FC F-Port 10:00:00:05:33:26:0e:65
FC F-Port 10:00:00:05:33:48:5e:f5
FC F-Port 10:00:00:05:1e:f8:a0:b3
FC F-Port 10:00:00:05:33:26:10:15
FC F-Port 10:00:00:05:1e:f8:a0:b1
FC F-Port 10:00:00:05:33:48:5e:d0
FC F-Port 10:00:00:05:33:26:df:6b
FC F-Port 10:00:00:05:33:26:df:6a
FC F-Port 10:00:00:05:33:48:6b:ea
FC F-Port 10:00:00:05:33:26:10:28
FC F-Port 10:00:00:05:33:26:10:73
FC F-Port 10:00:00:05:33:48:5e:d1
FC F-Port 10:00:00:05:33:26:10:29
FC F-Port 10:00:00:05:1e:f9:72:47
FC F-Port 10:00:00:05:33:26:0e:8a
FC F-Port 10:00:00:05:33:26:0e:8b
FC F-Port 10:00:00:05:33:48:6b:eb
FC F-Port 10:00:00:05:1e:f9:72:46
FC F-Port 10:00:00:05:33:26:10:14
FC F-Port 10:00:00:05:33:26:0e:64
