Downloading The Configuration - Broadcom Brocade DCX 8510-4 Backbone Hardware Installation Manual

53-1002177-19 Hardware Installation Guide
NOTE
New WWN cards are shipped preinstalled in the replacement chassis. Do not replace the WWN cards in the
replacement chassis with the old WWN cards from chassis that you are replacing. This will result in licensing
and return materials authorization (RMA) issues for your product. The original license will be transferred to the
replacement chassis, based on the license identification (LID) of the new, preinstalled WWN card, through the
RMA process. You should be provided a license for the new chassis through email. If you have not received this,
contact your Brocade support representative.
DANGER
For safety reasons, the ESD wrist strap should contain a series 1 megaohm resistor.
1. Record the chassis serial number, SKU, and WWN printed on the chassis label. This label is located on the lower left
corner of the chassis on the nonport side.
You may need this information to transfer licenses to the new chassis.
2. Record the chassis serial number, SKU, and WWN printed on the chassis label. This label is located on the lower right
corner of the chassis on the port side.
You may need this information to transfer licenses to the new chassis.
3. Replace the blower assemblies
4. Replace the power supplies or filler panels
5. Replace the control processor blades (CP8)
6. Replace the core switch blades (CR16-x)
7. If ICL cables are not used, insert EMI plugs in the ICL sockets in the core switch blades (CR16-x).
8. Replace the port blades or filler panels
filler panel removal and
9. Replace the cable management finger assemblies
10. Connect the power cords to the power supplies and the power outlets.
11. Replace the chassis door
12. Power on the device
The device performs a power-on self-test (POST). The POST takes a minimum of three minutes and is complete when
LED activity returns to the standard state.
13. Verify that the device is powered on and POST is complete (all power LED indicators on the blades should be a steady
green).
14. Verify that all components are functioning correctly by checking their LEDs. If the LEDs do not indicate correct
operation, try reinstalling the corresponding component.

Downloading the configuration

Once the chassis and its various components have been reassembled and powered back on, use the
command to restore the original configuration. The
session, but the device must have an Ethernet connection to the server name or IP address of the host for the download
process to complete. For more information, refer to the
Command Reference.
Complete the following steps to download the configuration.
1. Log in to the device as admin.
Broadcom
(Blower assembly removal and
(Power supply removal and
(Control processor blade (CP8) removal and
(Core switch blade (CR16-x) removal and
(Port application and encryption blade removal and replacement
replacement).
(Chassis door removal and
(Providing power to the
replacement).
(Vertical cable management fingers removal and
replacement).
device).
command can be entered through a Telnet or serial
configDownload
help configdownload
Brocade DCX 8510-4 Backbone Hardware Installation Guide
replacement).
replacement).
replacement).
command or the Brocade Fabric OS
and Blade
replacement).
configDownload
53-1002177-19
147
