Diagnostics and Troubleshooting

Introduction

For information about troubleshooting the entire fabric, refer to the Fabric OS Troubleshooting and Diagnostics Guide.
The device includes a number of diagnostic aids to assist with troubleshooting, including LEDs on the hardware,
commands that display current status, diagnostic tests for hardware and software, and error messages. In addition, a
number of managing and monitoring features are available, such as Fabric Manager, Web Tools, Fabric Watch, and
Advanced Performance Monitoring.
If the device does not operate as expected, the following steps can be taken to diagnose the problem:
•
Check the LEDs on system components on the front and back of the device and refer to the LED tables in the "System
Monitoring" section for interpretation and recommended actions.
•
Review the results of the last POST run by the device and refer to the "Interpreting POST and boot results" section for
more information.
•
Review the error logs. Refer to the Fabric OS Troubleshooting and Diagnostics Guide for more information.
–
Review RASlog entries.
–
Use the
sensorShow
–
Refer to "Diagnostics" in the "Diagnostics and Troubleshooting" section to run diagnostic tests.
–
Reboot the device or power entire chassis off and then on using procedures in
Powering off the chassis.
If the problem is still unresolved after these steps, contact your support provider.

Obtaining chassis and component status

The CLI commands in the following table provide status and environmental information about the chassis and its
components. These commands provide information only, and they do not interrupt traffic flow. For more information about
these commands, refer to the Brocade Fabric OS Command Reference.
Table 26: Environmental status and maintenance commands
sensorShow
tempShow
Temperature readings for the CP blades
psShow
fanShow
chassisShow
slotShow
errShowerrDump
Broadcom
command to determine the status of the hardware components.
Command
Brocade DCX 8510-4 Backbone Hardware Installation Guide
Providing power to the device
Information displayed
Temperature readings for the port blades
Temperature readings for the CP blades
Status and RPM of all operational fans
Status of all operational power supplies
Temperature readings for the port blades
Status of all operational power supplies
Status and RPM of all operational fans
Serial number, time awake, and additional information about each
component
Slot occupancy
System error log. Refer to the Brocade Fabric OS Message
Reference for more information on the messages in this log.
and
