53-1002177-19 Hardware Installation Guide
Checked?
Information about the new chassis
1. Open a Telnet session and log in to the device as admin. The default password is password. Enable the logging
function on your Telnet or serial console connection.
2. Back up the current configuration.
NOTE
If you are using the Virtual Fabric feature, you should run
configupload
•
Enter
configUpload -all
This command uploads the device configuration to the customer-defined FTP server, making it available for
downloading. For more information about this command, refer to the Brocade Fabric OS Command Reference.
switch:admin> configupload
Protocol (scp or ftp) [ftp]: ftp
Server Name or IP Address [host]: 123.123.123.123
User Name [user]: Admin24
File Name [config.txt]: config-switch0.txt
Password:
Upload complete
switch:admin>
•
Alternatively, you can save the configuration file to a Brocade USB device.
3. Record the WWN value: Enter
switch:admin> wwn
10:00:00:60:69:00:00:0a
4. Record the IP address information.
Enter ; then copy the command output into the config-miscinfo.txt file.
ipAddrShow
switch:admin> ipaddrshow
Chassis
Ethernet IP Address: 10.33.60.85
Ethernet Subnetmask: 255.255.240.0
CP0
Ethernet IP Address: 10.33.60.86
Ethernet Subnetmask: 255.255.240.0
Host Name: cp0
Gateway IP Address: 10.33.48.1
CP1
Ethernet IP Address: 10.33.60.87
Ethernet Subnetmask: 255.255.240.0
Host Name: cp1
Gateway IP Address: 10.33.48.1
Backplane IP address of CP0 : 10.0.0.5
Broadcom
New factory serial number
New serial number (if available)
command to save the logical switch configuration.
; then enter the requested information at the prompts.
; then copy the command output into a file named config-miscinfo.txt.
wwn
Brocade DCX 8510-4 Backbone Hardware Installation Guide
Data
configupload -vf
Notes
before running the
