Operating Guide | VLT® FCD 300 PROFIBUS Converter MCA 117

1 Introduction

1.1 Purpose of this Operating Guide

This operating guide provides information for the installation, commissioning, and parameter mapping of a VLT® FCD 300 PROFIBUS
Converter MCA 117 when installed in a VLT® Decentral Drive FCD 302.
The operating guide is intended for use by qualified personnel. Users are assumed to be familiar with:
• VLT® decentral drives.
• PROFIBUS.
Read the instruction before installation and ensure that the instructions for safe installation are observed.
Essential information for quick installation and setup is found in:
• 1.4.1 Intended Use
• 1.4.2 Hardware
• 3.1 Introduction to Installation
• 3.2 Electrical Installation
Detailed information including the full range of setup options and diagnosis tools is found in:
• 5 Parameter Mapping Lists
®
VLT is a registered trademark for Danfoss A/S.

1.2 Additional Resources

The following manuals may be helpful when installing the VLT® FCD 300 PROFIBUS Converter MCA 117:
• VLT® Decentral Drive FCD 302 Operating Guide.
• VLT® Decentral Drive FCD 302 Design Guide.
• VLT® AutomationDrive FC 301/FC 302 Programming Guide.
More manuals are available at www.danfoss.com.

1.3 Document and Software Version

This manual is regularly reviewed and updated. All suggestions for improvement are welcome.
The original language of this manual is English.
The converter is based on the latest firmware release of the VLT® Decentral Drive FCD300 and VLT® Decentral Drive FCM300.
The firmware versions are listed in
converter works, but may not convert parameters correctly.
Danfoss A/S © 2019.11
N O T I C E
table 1. If the FCD/FCM drive that has to be replaced has a older version (lower number) the
Introduction
AQ289550754901en-000101 / 130R0890| 5
