07 OTHER FUNCTIONS

[10] FIRMWARE UPGRADE

• The USB(Thumb drive) which contains the F/W file is needed for Firmware Upgrade.
• Select the SW UPGRADE in the SYSTEM menu.
1. Connect the USB to the USB Slot on the front of the monitor.
2. Select what to update among CPU / FPGA / ALL in [S/W UPGRADE].
3. When the USB connection is completed, the S/W upgrade starts and the progress displays on the
bottom left side of the screen.
4. If the USB doesn't connect properly or there is no fi le in the specifi ed location, the error message will
be displayed on the bottom left side of the screen and the upgrade won't start.
5. In that case, check the USB or the file location and try again.
• After USB connection, turn off and then on the monitor.
Field Production Monitor
33
