Internal Pattern - TVLogic F-10A Operation Manual

Field Production Monitor
07 OTHER FUNCTIONS

[9] INTERNAL PATTERN

• Displays internally generated test patterns.
- The pattern consists of ColorBar and Pluge+ Grayscale Patterns. Full screen colors of various gray levels
(0~100%) are also embedded.
<Color Bar + Pluge Pattern>
32
<Gray Pattern>
