TVLogic F-10A Operation Manual page 12

Field Production Monitor
05 MENU OPERATIONS
[2] COLOR
COLOR같이
STANDARD
VIDEO RANGE
PEAK LUMINANCE
BLACK LEVEL
COLOR GAMUT
COLOR TEMP
EOTF
LOCAL DIMMING
EETF
HLG SG
SG
THROUGHOUT
CAM LUT
CAM LUT THR
• STANDARD
- Used to select the color and dynamic rage of the
screen.
- Available options are HD, UHD, DCI-P3, PQ, HLG,
SLog3 and User1/2/3.
# Activates only in the User1/2/3 mode.
• VIDEO RANGE
- Used to select the range of digital video signal.
* FULL : Input signal 0~255 (8bit), 0~1023
(10bit) (When connecting the PC)
* LIMITED109 : Input signal Y': 16~235, CbCr:
16~240 (8bit)/ Y': 64~940, CbCr: 64-960 (10bit)
• PEAK LUMINANCE
- Used to select the Peak Luminance of the
monitor.
- Available options are 100, 200, 300, 400, 500,
600, 700, 800, 900, 1000, 2000, 4000 and 10000.
- Activates only in the User1/2/3 mode.
12
F-10A
UHD
LIMITED 109
100
0.001
BT.2020
6500K
2.4
OFF
OFF
OFF
OFF
OFF
OFF
PAGE (1/2)
• BLACK LEVEL
- The minimum black level of the video signal
can be set differently depending on the
performance of the monitor or the lighting
environment. For example, the lowest luminance
that the F-10A can display is 0.002, but it is
necessary to adjust the offset level to about
0.2nit when using under bright light.
- At this time, when the black level is set to 0.2,
dark gradations below 0.2 nit are expressed
without crushing.
- Activates only in the User1/2/3 mode.
• COLOR GAMUT
- Used to select the standard color gamut.
- Available options are BT.709, DCI-P3, BT.2020
and Native.
# The submenus may be activated in the User1/2/3
mode only.
• COLOR TEMP (Color Temperature)
- Controls the color temperature.
- Available options are 6500K, 9300K and User.
# The submenus may be activated in the User1/2/3
mode only.
• EOTF (Electro-Optical Transfer Function)
- Electrophotic conversion Functions(ex: Gamma
or HDR curve).
- Available modes are 2.2, 2.4, 2.6, PQ, HLG and
SLOG3.
# The submenus may be activated in the User1/2/3
mode only.
• LOCAL DIMMING
- Used to set the Local Dimming Backlight mode.
- This mode is supported by the local dimming
backlight model (LUM-310R) and does not
support F-10A.
