TVLogic F-10A Operation Manual page 31

07 OTHER FUNCTIONS
[8] HDMI To SDI SDI To HDMI CONVERSION-OUT / SDI To HDMI CONVERSION-OUT
HDMI TO SDI CONVERSION-OUT
• Video source from 'HDMI input' terminal can be
output through 'SDI throughout' terminal.
Output
Format
1080p50
Input
Format
480i(NTSC)
576i(PAL)
480P
576P
720P50
720P59.94
720P60
1080i50
1080i59.94
1080i60
1080p24
1080p25
1080p30
1080psF24
1080p50
1080p59.94
1080p60
Note: HDSLR camera manufacturers usually specify the resolution and frame rate for the recording. The
signal format that is output through HDMI terminal of cameras may differ from makers to makers. The
signal format for HDMI output and playback function of Canon HDSLRs is 59.94i. And even though 60i or
60p is specified in the specification of the cameras, the actual recording or HDMI output format would be
59.94i or 59.94p.
1080p60
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
SDI TO HDMI CONVERSION-OUT
3G/HD/SD SDI signals from'SDI input' terminal
●
can be output through'HDMI out'terminal.
Output
Format
1080p50
Input
Format
480i(NTSC)
576i(PAL)
720P50
720P59.94
720P60
1080i50
1080i59.94
1080i60
1080p24
1080p25
1080p30
1080psF24
1080p50
1080p59.94
1080p60
Field Production Monitor
1080p60
●
●
●
●
●
●
●
●
●
●
●
●
●
●
●
31
