08 AVAILABLE SIGNAL FORMATS

INPUT SIGNAL
480 / 59.94i (NTSC)
480 / 60p
576 / 50i (PAL)
576 / 50p
720 / 23.98p
720 / 24p
720 / 25p
720 / 30p
720 / 50p
720 / 59.94p
720 / 60p
1080 / 23.98PsF
1080 / 24PsF
VIDEO 1080 / 25PsF
1080 / 23.98p
1080 / 30PsF
1080 / 29.97PsF
1080 / 24p
1080 / 25p
1080 / 29.97p
1080 / 30p
1080 / 50i
1080 / 50p
1080 / 59.94i
1080 / 60i
1080 / 59.94p
1080 / 60p
640 x 400 (70Hz)
640 x 480 (60Hz)
640 x 480 (75Hz)
800 x 600 (60Hz)
800 x 600 (75Hz)
1024 x 768 (60Hz)
PC
1024 x 768 (70Hz)
1024 x 768 (75Hz)
1280 x 768 (60Hz)
1280 x 800 (60Hz)
1280 x 1024 (60Hz)
1920 x 1080 (60Hz)
34
DISPLAY CHARACTER EXAMPLE
720x480 60i
720x480 60p
720x576 50iW
720x576 50p
1280x720 24p
1280x720 24p
1280x720 25p
1280x720 30p
1280x720 50p
1280x720 60p
1280x720 60p
1920x1080 48i
1920x1080 48i
1920x1080 50i
1920x1080 24p
1920x1080 60i
1920x1080 60i
1920x1080 24p
1920x1080 25p
1920x1080 30p
1920x1080 30p
1920x1080 50i
1920x1080 25p
1920x1080 60i
1920x1080 60i
1920x1080 60p
1920x1080 60p
640x400 70p
640x480 60p
640x480 75p
800x600 60p
800x600 75p
1024x768 60p
1024x768 70p
1024x768 75p
1280x768 60p
1280x800 60p
1280x1024 60p
1920x1080 60p
SDI HDMI
● ●
●
● ●
●
●
●
●
●
● ●
● ●
● ●
●
●
●
● ●
●
●
● ●
● ●
● ●
● ●
● ●
● ●
● ●
● ●
● ●
● ●
●
●
●
●
●
●
●
●
●
●
●
●
