Chapter 3: BIOS Setup
Smart Fan Function
This section is used to configure the smart fan settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Advanced
Pc Health Status
Smart Fan Mode [Automatic Mode]
FAN Speed 30% under Temp: [35 C/ 95 F]
FAN Speed 100% above Temp: [75 C/167 F]
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Smart Fan Mode
Selects the mode of the fan, the options are Full on Mode and Automatic
Mode.
FAN Speed 30% under Temp
Configures the temperature for the fan speed to operate at 30% efficiency.
FAN Speed 100% above Temp
Configures the temperature for the fan speed to operate at 100% efficiency.
