Chapter 2: Connector Pinout Assignments
Pin Definition
A98 SER0_TX
A99 SER0_RX
A100 GND(FIXED)
A101 SER1_TX
A102 SER1_RX
A103 NC
A104 VCC_12V
A105 VCC_12V
A106 VCC_12V
A107 VCC_12V
A108 VCC_12V
A109 VCC_12V
A110 GND(FIXED)
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B98 RSVD
B99 RSVD
B100 GND(FIXED)
B101 FAN_PWMOUT
B102 FAN_TACHIN
B103 NC
B104 VCC_12V
B105 VCC_12V
B106 VCC_12V
B107 VCC_12V
B108 VCC_12V
B109 VCC_12V
B110 GND(FIXED)
Pin Definition
C98 PEG_RX14+
C99 PEG_RX14-
C100 GND(FIXED)
C101 PEG_RX15+
C102 PEG_RX15-
C103 GND
C104 VCC_12V
C105 VCC_12V
C106 VCC_12V
C107 VCC_12V
C108 VCC_12V
C109 VCC_12V
C110 GND(FIXED)
13
Pin Definition
D98 PEG_TX14+
D99 PEG_TX14-
D100 GND(FIXED)
D101 PEG_TX15+
D102 PEG_TX15-
D103 GND
D104 VCC_12V
D105 VCC_12V
D106 VCC_12V
D107 VCC_12V
D108 VCC_12V
D109 VCC_12V
D110 GND(FIXED)
