Chapter 2: Connector Pinout Assignments

EC JTAG

Connector type: 1x24 24-pin header
Connector location: CN1
24
Pin Definition
1 EC_KSO0
3 EC_KSO2
5 EC_KSO4
7 EC_KSO6
9 EC_KSO8
11 EC_KSO10
13 GND
15 GND
17 EC_KSI0
19 EC_KSI2
21 EC_KSI4
23 GND
Copyright © 2020 NEXCOM International Co., Ltd. All Rights Reserved.
1
Pin Definition
2 EC_KSO1
4 EC_KSO3
6 EC_KSO5
8 EC_KSO7
10 EC_KSO9
12 GND
14 GND
16 GND
18 EC_KSI1
20 EC_KSI3
22 EC_KSI5
24 GND
