Table 6-5 (Cont.) Acme Packet 1100 Environmental Specifications (cont.)
Specification
Maximum Altitude
Air Flow
Power Dissipation

Connector Specifications

Refer to the following table for information about the connector specifications for the Acme
Packet 1100.
Table 6-6 Acme Packet 1100 Connector Specifications (cont.)
Specification
RJ45/Management Ethernet
Ports
RS232/Serial Port
IEC Connector Ports
RJ48C T1/E1 Port (Optional)
Description
The Acme Packet 1100 System is required to operate below the
maximum altitude of 10,000 feet.
Single fan: 2.2 CFM (3.6 CFM Max)
Dual fans: 3.6 CFM (7.2 CFM Max)
10 Watts (maximum)
Description
The 3 x 8-pin RJ45 10/100 Ethernet ports are compliant with IEEE's
802.3, 802.3u, 802.1q and 802.3ab.
The RS232 serial port uses an 8-pin RJ45 connector that supports the
RS232-C protocol.
The IEC connector ports accept a 3-lead IEC-320 connector for AC
power installations.
Mechanical Arrangement: Miniature 8-position jack.
Usage: 1.544 Mbps digital services.
Electrical Network Connection: T&R, T1 R1, conductors 7 and 8
provide cable shield integrity.
