Specifications

This chapter provides information regarding the specifications of the Acme Packet 1100.

Safety and Regulatory Certifications

For information regarding safety and regulatory certifications applicable to the Acme Packet
1100, refer to the Acme Packet Platforms Safety and Compliance Guide in addition to this
chapter.

Acme Packet 1100 System Specifications

Table 6-1 Acme Packet 1100 System Specifications (cont.)
Specification
Height
Width
Depth
Weight
Ports
Onboard Transcoding &
QoS Measurement
Module
Mounting
LEDs
Memory
System Reset
Description
1.75 in (4.45 cm) (1U)
11.25 in (28.57 cm)
8.48 in (21.54 cm)
4.0 lbs (1.81 kg)
Four 10/100 Mbps Ethernet copper ports (RJ-45 connector) dedicated to
WAN, LAN, management and reserved functions
One T1/E1 port for PSTN fallback
Hardware-assisted transcoding and QoS monitoring and reporting
Table top
Rack mount flanges for front/rear/center installation in 19/23 in racks
(optional)
Wall mount brackets (optional)
Front: Ethernet link and activity status LEDs for PWR, NET MGT, INT, EXT,
and OK
Rear: Ethernet link and activity status LEDs for NET MGT, INT, EXT, and
T1/E1 link status
4 GB for active configuration and logs
40 GB fast M-SATA drive for runtime image, backup configurations and local
CDR backup
Reset pinhole
