Table A-5 Media Ethernet Link Alarm Information (cont.)
Alarm Name
LINK UP
ALARM
GIGPORT
LINK DOWN
ALARM
GIGPORT
LINK UP
ALARM
GIGPORT
LINK DOWN
ALARM
GIGPORT

Management Ethernet Link Alarms

The following table lists the management Ethernet port alarms.
Table A-6 Management Ethernet Link Alarm Information (cont.)
Alarm Name
LINK UP
ALARM
VXINTF
LINK DOWN
ALARM
VXINTF
(1) X denotes the number of alarming links.
Alarm Alarm Cause(s)
ID Severity
131073 MAJOR GigE S0P0 link
up
131074 MINOR GigE S0P0 link
down
131075 MAJOR GigE S0P1 link
up
131076 MINOR GigE S0P1 link
down
Alarm Alarm Cause(s)
ID Severity
131077 MINOR Mgmt0 link up
131080 MAJOR Mgmt0 link
down
Link and SDP Alarms
Example Log Graphic Display Message
Message
Slot 0 port 0 UP X LINK ALARMS (where
X is number of alarming
links)
Slot 0 port 0 X LINK ALARMS
DOWN
Slot 0 port 1 UP X LINK ALARMS
Slot 0 port 1 X LINK ALARMS
DOWN
Example Log Graphic Display
Message Message(1)
Port 0 UP X LINK ALARMS
Port 0 DOWN X LINK ALARMS
